Fiberglass Filtration Mesh

Get a Price/Quote

MOQ : 30 Square Meters

Fiberglass Filtration Mesh Specification

Usage & Applications
Molten metal filtration, dust collection, air and water filtration, insulation reinforcement

GSM
125 to 300 GSM

Shape
Roll, Sheet, or Customized

Coating Type
Phenolic, PTFE, Resin, or Graphite

Temperature
Up to 800C

Thickness
0.8 mm to 1.8 mm

Thermal Conductivity
Low / Insulating

Material
Fiberglass

Application
Industrial filtration, foundry metal filtration, air and liquid filtration

Technique
Woven

Dimension (L*W*H)
Customized, typically 1m x 50m roll

About Fiberglass Filtration Mesh

We are offering our clients supreme quality Fiberglass Filtration Mesh that is cloth woven with fiberglass yarn. This non-alkali mesh is widely used for filtering the molten metals, especially aluminum or aluminum alloys. Further, this suitable filtration medium has excellent dimensional stability, temperature resistance and lowest elongation. It is also suitable for filtration of dust laden hot gases. Easy to handle and maintain, this environment friendly product has good filtration performance. We can also customize this product as per the requirements of clients.

Versatile Filtration Applications

Our fiberglass filtration mesh is engineered to meet the rigorous requirements of industrial filtration. It is specifically designed for molten metal filtration in foundries, dust collection, and air and liquid filtration tasks. Its robust construction also makes it valuable for insulation reinforcement. The adaptability and customizable dimensions ensure it fits seamlessly into various industrial processes, offering dependable performance and longevity.

High Thermal Resistance and Superior Durability

Crafted from premium fiberglass, this mesh withstands high temperatures up to 800C, making it suitable for extreme industrial environments. Low thermal conductivity ensures minimal heat transfer, protecting equipment and improving operational safety. The mesh is available with advanced coatings like PTFE, phenolic, resin, or graphite, further enhancing its chemical and thermal resilience.

Customizable Formats for Diverse Needs

We offer fiberglass filtration mesh in rolls (typically 1m x 50m), sheets, and other customized forms to align with unique industry requirements. Thicknesses range from 0.8 mm to 1.8 mm, and GSM from 125 to 300, catering to a wide spectrum of filtration and reinforcement applications. Whether you require bulk supplies as an exporter, importer, manufacturer, supplier, or trader, our solutions are tailored for efficiency and adaptability.

FAQs of Fiberglass Filtration Mesh:

Q: How is fiberglass filtration mesh used in molten metal filtration?

A: Fiberglass filtration mesh is commonly placed in gating systems of foundries to remove impurities from molten metal during casting. Its high-temperature resistance and woven structure trap contaminants, ensuring cleaner metal and higher quality castings.

Q: What coatings are available for the fiberglass filtration mesh, and what are their benefits?

A: Our meshes can be coated with phenolic, PTFE, resin, or graphite. These coatings enhance chemical and temperature resistance, improve filtration efficiency, and enable use in specialized applications such as aggressive chemical environments or very high-temperature conditions.

Q: When should I choose a customized dimension or thickness for my application?

A: Customized dimensions and thicknesses are ideal when standard sizes do not fit your filtration equipment or when specific process requirements dictate unique mesh properties. Customization ensures optimal performance and efficiency in specialized industrial operations.

Q: Where can fiberglass filtration mesh be applied beyond foundry metal filtration?

A: Besides molten metal filtration, this mesh is used in dust collection units, air and water filtration systems, and as a reinforcing layer in insulation products. Its versatility makes it suitable for a range of industries requiring high-performance filtration and thermal resistance.

Q: What is the manufacturing process for fiberglass filtration mesh?

A: The mesh is produced by weaving fine fiberglass yarns, followed by applying specific coatings (phenolic, PTFE, resin, or graphite) for enhanced properties. The final product is cut into rolls, sheets, or customized shapes per client requirements.

Q: How does fiberglass filtration mesh benefit industrial processes?

A: It improves product quality by trapping contaminants, enhances operational safety through insulation and thermal resistance, and extends equipment lifespan. Its chemical durability and customizable options also provide cost-effective solutions for multiple industrial challenges.
